Gresham Power Electronics has announced it is adding a number of new models to its range of encapsulated convection cooled power supplies.

Applications for the Gresham Power GPL range include instrumentation, test equipment, medical electronics and equipment operating in harsh environments.

The GPL series of encapsulated linear power supplies is now available with output voltages from 5-250VDC at up to 25W and input voltages of 105-125VAC or 220-240VAC. Single output versions are available over the range 5-24VDC, dual outputs ±5, ±12 or ±15VDC and triple output versions have voltage options of 5/±12 or 5V/±15.

PCB and chassis mount versions are available with optional finger safe terminals and all models feature short circuit protection. The operating temperature range of the Gresham GPL series is -25 to +71°C and a 400Hz input frequency version is available on request.

Industrial and medical approvals are met with medical versions offering extra low noise, IEC 60601-1 with 2MOPP (4000VAC reinforced insulation and 8mm creepage distance) and 2μA Patient Leakage Current.
