SSBN Typhoon Class (Type 941), Russia




The Typhoon ballistic missile nuclear-powered (SSBN) submarines are the largest submarines ever to be built. They were constructed at the Severodvinsk Shipyard, on the White Sea near Archangel.

The first of the six members of the class to be commissioned was TK 208 in 1981, followed by TK 202 in 1983, TK 12 in 1984, TK 13 in 1985, TK 17 in 1987 and TK 20 in 1989. The submarines were stationed with the Russian Northern Fleet at Litsa Guba.

Of the six, only TK 17 and TK 20 are operational. TK 208 was relaunched following refit in 2002 and is being used as a trials ship. TK 12 and TK 13 are decommissioned, waiting to be scrapped.

With assistance from the United States, through the cooperative threat reduction programme, TK 202 has had its nuclear fuel removed by US funded processing facilities and converted into forms suitable for long-term storage or reuse. The UK has also agreed to take part in the dismantling of Russia's decommissioned nuclear submarines.

Design

The Typhoon Class submarine is of multi-hulled design – five inner hulls are situated inside a superstructure of the two parallel main hulls. The superstructure is coated with sound-absorbent tiles. There are 19 compartments including a strengthened module which houses the main control room and electronic equipment compartment which is above the main hulls behind the missile launch tubes.

"The Typhoon Class submarine is of multi-hulled design, with five inner hulls."

The submarine's design includes features for travelling under ice and ice-breaking. It has an advanced stern fin with horizontal hydroplane fitted after the screws. The nose horizontal hydroplanes are in the bow section and are retractable into the hull.

The retractable systems include two periscopes (one for the commander and one for general use), radio sextant, radar, radio communications, navigation and direction-finder masts.

They are housed within the sail guard. The sail and sail guard have a reinforced rounded cover for ice-breaking.

Maximum diving depth is 400m. Speed is 12kt when surfaced and 25kt when submerged. Typhoon is capable of spending 120 days at sea.

Missiles

The submarine carries 20 RSM-52 intercontinental, three-stage solid propellant ballistic missiles. The two rows of missile launch tubes are situated in front of the sail between the main hulls.

Each missile consists of ten independently targetable multiple re-entry vehicles (MIRV's), each with a 100kt nuclear warhead. Guidance is inertial with stellar reference updating. Range is 8,300km with accuracy (CEP) of 500m. The missile weighs 84,000kg at launch and was designed by the Makayev Design Bureau. It has the NATO designation of SS-N-20 Sturgeon.

In September and December 2005, the Dmitry Donskoy carried out successful flight tests of a new solid fuel intercontinental ballistic missile, the SS-N-30 Bulava, being developed for the Russian Navy. Bulava is reported to have a range of more than 8,000km and to be able to carry a 550kt nuclear warhead. It is based on the land-launched Topol missile (SS-27). Bulava is to arm the Russian Navy’s new Borey Class submarines from 2008 and may be retrofitted to the Typhoon Class.

Torpedoes

Typhoon has four 630mm torpedo tubes and two 533mm torpedo tubes with a total of 22 anti-submarine missiles and torpedoes of varying types. The torpedo room is in the upper part of the bow between the hulls. The torpedo tubes can also be used to deploy mines.

Systems

The sonar is an active / passive search and attack type with the sonar mounted on the hull under the torpedo room. The submarine is fitted with I/J-band surface target detection radar.

"Typhoon has four 630mm torpedo tubes and two 533mm torpedo tubes with a total of 22 anti-submarine missiles and torpedoes."

Countermeaures include ESM (electronic support measures), radar warning system and direction-finding system.

The submarine has both radio and satellite communications systems. It is fitted with two floating antenna buoys to receive radio signals, target designation data and satellite navigation signals, at depth and under ice cover.

Propulsion

The submarine main machinery consists of two nuclear water reactors and two turbogear assemblies comprising steam turbine and gearbox. One reactor and one turbogear assembly are fitted in each main hull.

Each nuclear water reactor produces 190MW. These drive two 50,000hp steam turbines and four 3,200kW turbogenerators. Two 800kW diesel generators serve as standby propulsion units and are coupled to the shaft line. The two propellers are seven-blade, fixed-pitch shrouded. The built-in thrusters on the bow and stern are two telescopic turning screw rudders and are powered by a 750kW motor.

Two snow covered Russian submarines in port setting Two Typhoon Class submarines, part of the Russian Northern Fleet.
Typhoon Class Russian submarine on manoeuvres. Typhoon Class on manoeuvres.
Retractable masts of a Russian submarine on display Typhoon Class showing sail with retractable masts.
Ice covered Russian submarine equipped with ice-breaking equipment The submarine's design includes features for travelling under ice and ice-breaking.
Russian submarine shown with missile hatches open The deck with missile hatches open.
The control room of a Typhoon Class Russian submarine Typhoon Class control room.
Image of a Russian submarine in port setting The submarine carries 20 RSM-52 intercontinental, three-stage solid propellant ballistic missiles.
Line drawings of a Typhoon Class Russian submarine. Line drawing of Typhoon Class submarine.
