EA-18G Growler Electronic Attack Aircraft, United States of America




Key Data


EA-18G Growler Electronic Attack Aircraft

The EA-18G Growler is an airborne electronic attack (AEA) aircraft which operates from either an aircraft carrier or from land-bases. The Growler has been developed as a replacement for the United States Navy EA-6B Prowler aircraft which entered service in 1971 and is approaching the end of operational life.

The Growler is a derivative of the combat-proven two-seat F/A-18 Hornet, the US Navy's maritime strike aircraft. The aircraft missions are mainly electronic attack (EA) and suppression of enemy air defences (SEAD), particularly at the start and on-going early stages of hostilities.

"The EA-18G Growler is an airborne electronic attack (AEA) aircraft."

The Growler aircraft has 11 weapon stations for carrying electronic mission systems and weapons and can then be used to carry out conventional strike missions when the requirements for EA and SEAD sorties are reduced.

EA-18G Growler programme and development

The US Navy awarded a five-year system development and demonstration (SDD) contract in December 2003. A contract for the first four production aircraft was signed in July 2006.

The Growler aircraft's first test flight was successfully completed in August 2006. This was followed by delivery of the first two test aircraft to the USN in September and November 2006. The first production aircraft was delivered to the USN in September 2007.

The first operational aircraft was delivered to NAS Whidbey Island in June 2008 and operational evaluation began in October 2008 onboard the USS John C Stennis (CVN 74) aircraft carrier. The SDD programme will conclude with an initial operational capability in late 2009 when the first of ten electronic attack squadrons (VAQ) will begin EA-18G operations. Deliveries of 88 Growler aircraft are planned to conclude in 2013. In service the aircraft will carry out a range of missions including stand-off and escort jamming, surveillance and strike.

Naval Air Systems Command PMA-265 is the US Navy acquisition office for the EA-18G. The Boeing Company is the prime contractor and weapon system integrator and Boeing also leads the EA-18G Growler industry team. Northrop Grumman is the principal subcontractor and airborne electronic attack subsystem integrator.

The EA-18G Growler fleet will be based at Naval Air Station Whidbey Island, Washington.

Growler cockpit

The two-seat cockpit has the pilot crew station and the electronic warfare officer's advanced crew station. The advanced crew station is equipped with a touch-screen liquid crystal display (LCD) mission systems control and display, a 203mm x 23mm (8in x 10in) full-colour tactical LCD, and two multipurpose 127mm x 127mm (5in²) LCDs. The displays have tactical aircraft moving map capability (TAMMAC).

"The Growler is a derivative of the combat-proven two-seat F/A-18 Hornet."

The aircraft is equipped with HOTAS hands-on throttle and stick control and full digital fly-by-wire controls.

The aircraft is fitted with a helmet-mounted cueing system developed by the Rockwell Collins and Elbit joint venture company, Vision Systems International.

The HMCS provides 'first look, first shot' high off-boresight weapons engagement capability.

The system enables the pilot to accurately direct or cue the weapons against enemy aircraft while performing high-g manoeuvres. The pilot points his head at the target and weapons are directed to the target. Aircraft and mission data such as targeting cues and aircraft performance parameters are displayed directly on the pilot's visor.

EA-18G electronic warfare

The EA-18G integrates advanced airborne electronic attack capabilities, developed and manufactured by Northrop Grumman, with the advanced strike capabilities, including advanced weapons, sensors and communications systems, installed on the F/A-18 Super Hornet aircraft.

The block 1 Growler is fitted with up to three AN/ALQ-99 radar jamming pods, together with an AN/ALQ-218(V)2 receiver and a Raytheon AN/ALQ-227 communications countermeasures system both of which are mounted in the bay previously designated as the F/A-18 Hornet aircraft's gun bay.

The AN/ALQ-99 jammer fitted on the block 1 Growler is supplied by the EDO Corporation. The AN/ALQ-99 receivers are installed in the tail of the aircraft and the AN/ALQ-99 pod houses the exciters and the high radiated power jamming transmitters.

"The Growler aircraft has 11 weapon stations for carrying electronic mission systems and weapons."

The block 2 Growler is equipped with the APG-79 multi-mode radar with passive detection mode and active radar suppression, ALQ-218(V)2 digital radar warning receiver and ALE-47 countermeasures dispenser.

The advanced tactical radar, the APG-79 Active Electronically Scanned Array (AESA) radar provides air-to-air and air-to-ground capability with detection, targeting, tracking and protection modes. The radar is supplied by Raytheon Space and Airborne Systems at El Segundo, California.

The interleaved radar modes include real beam-mapping mode and synthetic aperture radar mode with air-to-air search, air-to-air tracking, sea surface search and ground moving target indication and tracking. The radar has an advanced four-channel receiver-exciter which provides wide bandwidth capability and the ability to generate a wide range of waveforms for electronic warfare, air-to-air and air-to-ground operation. It also has the ability to operate in multiple air-to-air and air-to-ground modes simultaneously.

The AN/ALQ-218(V)2, developed by Northrop Grumman Electronic Systems, is a variant of the Improved Capabilities (ICAP) III system deployed on the US Navy's EA-6B Prowler aircraft. The system's antennas are located on the port and starboard sides of the nose, the engine bays, in the wingtip pods and to the aft of the cockpit, providing 360° azimuthal cover. The passive countermeasures system provides threat detection, identification and location.

The ALE-47 countermeasures dispenser supplied by BAE Systems Electronics and Integrated Systems in Austin, Texas, can be used with US and NATO radar and infrared decoys.

Growler weapons

The aircraft is armed with the AIM-120 AMRAAM advanced medium-range air-to-air missiles and AGM-88 HARM high-speed anti-radiation missiles.

"The EA-18G Growler fleet will be based at Naval Air Station Whidbey Island, Washington."

In a surveillance-only configuration the Growler is armed with two AIM-120 air-to-air missiles for self defence. For stand-off jamming and escort jamming missions the Growler is armed with two AGM-88 anti-radiation missiles plus two AIM-120 missiles. In a strike configuration the Growler is armed with two each of AGM-88 HARM missiles, AGM-154 JSOW joint stand-off weapon (block 2 aircraft) and AIM-120 air-to-air missiles. While carrying out active transmitting jamming, the block 2 aircraft has the capability of handing off target data to other airborne, land or surface attack platforms.

EA-18G and F/A-18F design

The EA-18G Growler aircraft is a derivative of the F/A-18F Super Hornet with structural changes and the installation of avionics and mission systems, increasing the empty weight by 800kg to 15,000kg and increasing the carrier landing weight by 1,350kg to 21,775kg.

One of the external visual characteristics is the wingtip air-to-air missiles on the F/A-18 Super Hornet are normally replaced by wideband receiver pods on the EA-18 Growler and the other hardpoints carry a mix of electronic warfare pods and weapons.

The aircraft construction includes a light alloy multispar wing and high-strength graphite and epoxy panels and doors. The major contractor Northrop Grumman manufactures the rear and centre fuselage sections and EADS CASA is responsible for the manufacture of structural components such as the fuselage rear side panels, horizontal tail surfaces, flaps, the leading edge extensions, the rudders and the speed brakes.

"The Growler aircraft's first test flight was successfully completed in August 2006."

The aircraft has retractable tricycle-type landing gear. The Menasco main landing gear is single wheeled and turns through 90° to retract rearward into the wheel bays mounted in the engine air ducts. The aircraft has a Messier-Dowty twin-wheel nose gear. The nose of the aircraft is fitted with a catapult launch tow bar. An arrester hook is installed under the rear section of the fuselage.

Turbofan engine

The Growler is powered by two F414-GE-400 afterburning turbofan engines, supplied by General Electric. A titanium engine firewall is incorporated into the aircraft structure. The engines are rated to supply 62kN or 98kN with afterburn.

The first flight of the EA-18G Growler, the US Navy's new airborne electronic attack (AEA) aircraft, was in August 2006.
The EA-18G Growler's primary missions are electronic attack (EA) and suppression of enemy air defences (SEAD). It has eleven weapon stations for carrying electronic mission systems and weapons.
Roll-out of the EA-18G in August 2006. The Growler will replace the EA-6B Prowler, in service since 1971, in the US Navy.
The EA-18G Growler combines advanced airborne electronic attack (AEA) with the advanced strike capabilities of the
F/A-18 Super Hornet.
Boeing is the prime contractor and weapon system integrator for the EA-18G Growler and leads the industry team, which includes Northrop Grumman as principal subcontractor and airborne electronic attack subsystem integrator.
Simulation equipment in the dedicated
EA-18G integration laboratory at Boeing.
